The Fluke 115 True RMS Digital Multimeter is the ideal tool for general electrical and electronic testing. Compact and easy to operate with one hand, it suits the needs of field service technicians. With 6000-count resolution, it accurately measures True RMS voltage and current, along with resistance, continuity, frequency, and capacitance for fast and reliable checks.

Category	Specification
DC Millivolts	Range/Resolution: 600.0 mV / 0.1 mV Accuracy: 0.5% + 2
DC Volts	Ranges: 6.000 V / 60.00 V / 600.0 V Resolution: 0.001 V / 0.01 V / 0.1 V Accuracy: 0.5% + 2
AC Millivolts (True RMS)	Range/Resolution: 600.0 mV / 0.1 mV Accuracy: 1.0% + 3 (45 Hz to 500 Hz) 2.0% + 3 (500 Hz to 1 kHz)
AC Volts (True RMS)	Ranges: 6.000 V / 60.00 V / 600.0 V Resolution: 0.001 V / 0.01 V / 0.1 V Accuracy: 1.0% + 3 (45 Hz to 500 Hz) 2.0% + 3 (500 Hz to 1 kHz)
Continuity	Range/Resolution: 600 Ω / 1 Ω Beeper on < 20 Ω, off > 250 Ω
Resistance (Ohms)	Ranges: 600.0 Ω to 6.000 MΩ Accuracy: 0.9% + 1 40.00 MΩ range accuracy: 5% + 2
Diode Test	Range/Resolution: 2.00 V / 0.001 V Accuracy: 0.9% + 2
Capacitance	Ranges: 1000 nF to 9999 μF Accuracy: 1.9% + 2 (≤1000 μF) >1000 μF: 5% + 20%
Lo-Z Capacitance	Range: 1 nF to 500 μF Accuracy: 10% + 2 (typical)
AC Current (True RMS)	Ranges: 6.000 A / 10.00 A Resolution: 0.001 A / 0.01 A Accuracy: 1.5% + 3 20 A overload (30 seconds max)
DC Current	Ranges: 6.000 A / 10.00 A Resolution: 0.001 A / 0.01 A Accuracy: 1.0% + 3 20 A overload (30 seconds max)
Frequency (V or A Input)	Ranges: 99.99 Hz to 50.00 kHz Resolution: 0.01 Hz to 0.01 kHz Accuracy: 0.1% + 2
Maximum Voltage	600 V between any terminal and earth ground
Safety Rating	IEC 61010-1: Pollution Degree 2 IEC 61010-2-033: CAT III 600V
Display	6,000 count digital display (4 updates/sec) 33 segment bar graph (32 updates/sec)
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +60°C
Battery	9V Alkaline (IEC 6LR61) Approx. 400 hours battery life (without backlight)
Dimensions	167 × 84 × 46 mm
Weight	550 g
Warranty	3 Years

Manuals & Videos	Fluke – User Manual (PDF) Download Full Manual Fluke – User Manual (PDF) Download Full Manual Fluke 114 – Service Manual (PDF) Download Full Manual Fluke 114 – Calibration Information (PDF) Download Full Document Fluke – User Manual (PDF) Download Full Manual Fluke 114 – User Manual (PDF) Download Full Manual
Specifications Description	True RMS Accuracy: Provides precise measurements for AC voltage and current on non-linear signals. Versatile Measurement Functions: Measures AC/DC voltage up to 600V, AC/DC current up to 10A, resistance, continuity, frequency, and capacitance. Min/Max/Average Recording: Captures signal fluctuations for comprehensive analysis. Bright LED Backlight: Large white LED backlight for easy viewing in poorly lit areas. Safety Rated: CAT III 600V safety rating ensures reliable protection during electrical testing. Compact and Ergonomic Design: Allows for one-handed operation and fits comfortably in a tool bag or pocket. Holster with Probe Holders: Comes with a holster for easy storage and transport. General Specifications Maximum Voltage Between any Terminal and Earth Ground: 600 V Safety: IEC 61010-1: Pollution Degree 2; IEC 61010-2-033: CAT III 600V Display: Digital, 6,000 counts, updates 4 times/sec; Bar graph, 33 segments, updates 32 times/sec Operating Temperature: -10°C to +50°C Storage Temperature: -40°C to +60°C Battery Type: 9V Alkaline, IEC 6LR61 Battery Life: 400 hours typical, without backlight Size: 167 x 84 x 46 mm (6.57 x 3.31 x 1.82 in) Weight: 550 g Warranty: 3 years Includes: Holster Installed 9V battery 4 mm silicone test lead set User manual
Package Weight (kg)	0.740000
Package Length (cm)	26.40
Package Width (cm)	15.00
Package Height (cm)	6.20
Manufacturer	FLUKE
Consignment	No

Fluke 115 Digital Multimeter for Technicians

Find a Store

Technical Specifications

Key Features

What’s Included

Compatible Accessories

Frequently Asked Questions

Includes:
